Hydrogen
Product origin: China
Delivery time: About 30days after down payment
99.999% (5N) high purity hydrogen
1. Ultra high purity and consistency: 99.999% (5N) high purity hydrogen, meeting the impurity control requirements of high-end applications and ensuring stable process and product quality.
2. Excellent cleanliness and reducibility: Hydrogen combustion produces only water, zero carbon emissions, and effectively reduces oxides to ensure material purity.
3. Guaranteed supply security: High purity hydrogen is packaged and supplied in multiple specifications, following international safety standards throughout the entire process, covering production, storage, transportation, and use.
99.999% (5N) high purity hydrogen
INDEX
| NO | Name | Chemical formula | Purity(%) | Pressure(Mpa) | Filling weight(m3/kg) | Valve|male outlet connection | Cylinder volume(L) | Cylinder size(cm) | Cylinder tare weight(kg) |
| 1 | hydrogen | H2 | 99.9 | 11 | 4.4 | W21.8left-hand thread | 40 | 29×145 | 50 |
| 2 | High Purity Hydrogen | H2 | 99.999 | 11 | 4.4 | W21.8left-hand thread | 40 | 29×145 | 50 |
| 3 | High Purity Hydrogen | H2 | 99.999 | 9.5 | 1 | W21.8left-hand thread | 8 | 22×75 | 10 |
Packaging
Standard export packing
Main application areas
·Electronic semiconductor industry:
·Wafer manufacturing: High purity hydrogen gas is used as the carrier gas and reducing gas for epitaxial growth and chemical vapor deposition (CVD).
·Chip packaging: High purity hydrogen provides a protective atmosphere to prevent the chip from being oxidized at high temperatures.
·Photovoltaic new energy:
·Hydrogen is used as a protective gas and reducing gas in the production process of polycrystalline silicon and monocrystalline silicon, and is a key material for manufacturing efficient solar cells.
·High end manufacturing industry:
·Optical fiber: Hydrogen gas is used as a protective gas for the sintering process of prefabricated rods.
·Float glass: Hydrogen gas provides a protective atmosphere in the tin bath, producing high-quality flat glass.
·Stainless steel heat treatment: Hydrogen provides a bright annealing protective atmosphere to ensure the smoothness of the metal surface.
·Analysis and Research:
·As a carrier gas for high-end analytical instruments such as gas chromatography (GC) and mass spectrometry, the purity of hydrogen directly affects the accuracy and precision of the analysis results.
·New material research and development:
·Hydrogen is used for the preparation of new materials such as graphene and carbon nanotubes.
Storage and transportation requirements
-Storage requirements: Special stainless steel or aluminum alloy high-pressure hydrogen storage tanks (usually working pressure of 15MPa or 35MPa) or low-temperature liquid hydrogen storage tanks (storing liquid hydrogen at -252.87 ℃) must be used. The tanks must undergo strict pressure resistance and sealing tests, and be equipped with pressure monitoring, safety valves, emergency shut-off valves, and leak alarm devices; The storage location should be independently set up, away from fire sources, heat sources, oxidants, and densely populated areas. Explosion proof electrical equipment should be used, anti-static materials should be used on the ground, and a good ventilation system should be set up (with no less than 12 ventilation times per hour); It is strictly prohibited to mix with oxidizing gases such as oxygen, chlorine, fluorine, etc. Hydrogen storage tanks must undergo regular non-destructive testing and calibration.
-Transportation requirements: Enterprises and specialized transportation equipment with hazardous chemical transportation qualifications shall be used. High pressure tank trucks (made of stainless steel or aluminum alloy) shall be used for gaseous ultra pure hydrogen, and low-temperature insulated tank trucks shall be used for liquid hydrogen; Transport vehicles must be equipped with explosion-proof and anti-static devices, as well as emergency leak prevention equipment. Drivers and escorts must have corresponding qualifications and be familiar with emergency response procedures; During transportation, it is necessary to comply with traffic control regulations, avoid densely populated areas and high temperature and high humidity environments, and strictly prohibit smoking and hot work during transportation; Before transportation, it is necessary to check the sealing and pressure status of the storage tank, and conduct regular inspections during transportation to prevent leaks; During long-distance transportation, it is necessary to plan a dedicated transportation route and report in advance.
