Main Technical Data：

Design Temperature：50 Celsius

Design Pressure：10.0 MPA

Volum：11.3M3

Proof pressure：12.5Mpa

Net weight：13673KG

Working medium：O2

Core strengths

1. Compact structure, high space utilization rate

Compared to vertical storage tanks, horizontal storage tanks adopt a cylindrical structure placed horizontally, occupying a smaller area, and are particularly suitable for scenarios such as limited factory space and narrow outdoor areas. The equipment can adjust the length and diameter ratio according to the actual size of the site, flexibly adapt to different installation environments, and can be deployed without the need for large-scale site renovation, effectively reducing the initial infrastructure costs.

2. Stable operation and strong impact resistance

The storage tank body is made of high-quality corrosion-resistant and high-strength materials such as carbon steel, stainless steel (304/316L), and fiberglass. It is manufactured through precision processes such as coil forming, automatic welding, and non-destructive testing. The overall structural strength is high and can withstand certain pressure and impact. The horizontal storage tank design ensures a more uniform distribution of the medium inside the tank, reducing the impact force on the tank body when the liquid level changes. Combined with professional support structures (such as saddle supports), it can effectively disperse the weight of the tank body, reduce vibration, and ensure long-term stable operation.

3. Customization is flexible and adaptable to multiple media

We can provide fully customized services for the storage needs of different industries: starting from the characteristics of the medium, choose the corresponding anti-corrosion materials (such as using plastic or stainless steel materials for storing corrosive liquids, and equipping insulation layers for storing high-temperature media); Customize storage tanks with different volumes ranging from 5-1000m ³ according to storage capacity requirements; At the same time, it can integrate supporting components such as liquid level gauges, pressure gauges, safety valves, drain valves, mixing devices, etc., to meet multiple needs such as medium storage, metering, mixing, and safety protection.

4. Convenient operation and low maintenance cost

There are convenient inspection ports and observation windows on the side of the storage tank, making it easy for staff to regularly check the internal condition; The bottom of the storage tank adopts an inclined design, combined with a drain valve, which can quickly discharge residual media and impurities in the tank, reducing the difficulty of cleaning. The overall failure rate of the storage tank is low, and the key vulnerable components have strong universality and easy replacement, which can effectively reduce maintenance costs and downtime losses in the later stage.

Applicable scenarios:

Petrochemical industry: Storage tanks are used to store crude oil, diesel, lubricating oil, chemical solvents, acid-base solutions, etc. Corrosion resistant materials can effectively prevent the reaction between the medium and the tank body, ensuring storage safety.

Energy and power industry: Storage tanks are used to store the necessary media for the operation of equipment such as transformer oil, hydraulic oil, and cooling water. The stable structural design is suitable for harsh operating environments such as power plants and substations.

Pharmaceutical and food industry: The storage tank is made of 304/316L stainless steel material and can store drinking water, food raw materials, medicinal liquids, alcohol, etc. It meets GMP hygiene standards to ensure the purity of the medium is not contaminated.

Municipal environmental protection industry: Storage tanks are used for chemical storage in sewage treatment plants, clean water storage in water plants, leachate storage in garbage treatment plants, etc. The large volume design meets the needs of municipal batch storage.

Agriculture and Manufacturing: Storage tanks store production materials such as pesticides, fertilizers, coatings, inks, lubricants, etc. Customized anti-corrosion and sealing designs are adapted to the characteristics of various industrial raw materials.

Quality assurance:

We always prioritize product quality and have established a full process quality control system from raw material procurement to finished product delivery: all raw materials are made of high-quality steel from well-known brands and undergo material testing before entering the site; The production process adopts precision equipment such as CNC rolling machines and automatic submerged arc welding machines. Key welds undergo non-destructive testing such as X-ray inspection and hydrostatic testing to ensure welding quality; Before leaving the factory, finished storage tanks need to undergo multiple inspections such as sealing tests, pressure tests, and appearance inspections to meet industry standards.
